ICON 05-07 Ford F-250/F-350 7in Stage 1 Suspension System

Manufacturer Part # : K67100

Market Description

ICON’s 7” Suspension System for the 2005-2007 Ford Super Duty offers unparalleled performance and ride quality while giving the vehicle clearance for 38” Tall tires. This system comes complete with ICON 2.0 Aluminum Series Shocks, Dual Rate Coil Springs, Drop Pitman Arm, Pan Rod Bracket, Brake Line Brackets, Radius Arm Drop Down Brackets, ICON's Fabricated 6" Blocks and U-bolts. All of these components (excluding shocks) are covered by ICON’s Limited Lifetime Warranty.

Associated Comments

• APPLICATION NOTE #29: 7” Systems Using A 4-Link In Place Of The Factory Radius Arms Do Not Require The Use Of Alignment Cams. Caster Can Be Adjusted By The Lower Link Arms
• APPLICATION NOTE #28: Pinch Weld On ‘05-’10 Superduty Radius Arms May Come In Contact With Radius Arm Drop Bracket Hardware
• Recommended Aftermarket Tires: 37" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
• APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
• APPLICATION NOTE #56: Rear Add-A-Leaf Required For Truck To Sit Level When Using 6” Block Included In Kit
• Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 5.00” Backspace / 6mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.25” Backspace / 6mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.25” Backspace / 6mm Offset
• APPLICATION NOTE #21: NOT APPLICABLE ON VEHICLES EQUIPPED WITH A MANUAL TRANSMISSION
• APPLICATION NOTE #6: SPRINGS ARE RATED FOR DIESEL ENGINES ONLY
• OEM Wheels & Tires Fitment: Yes
• Ships in multiple boxes

Features and Benefits

• 100% Bolt-on system - No drilling, cutting, or welding necessary
• 7” more travel from ride height to front bump stops
• Lifetime guarantee that coil springs won’t sag
• State of the art dual-rate coil spring
• No drive shaft modifications needed
• 75% increase in wheel travel
• No change in towing capacity
• Less body roll than stock
• Clears 38" Tall Tires

Product Description - Extended

2005-2007 FORD F-250/F-350 7" LIFT STAGE 1 SUSPENSION SYSTEM

Product Description - Short

• ICON 05-07 Ford F-250/F-350 7in Stage 1 Suspension System
• SUSPENSION SYSTEM

Product Description - Long

05-07 FORD F-250/F-350 7" STAGE 1 SUSPENSION SYSTEM

Product Description - Invoice

05-07 F-250/F-350 7" STAGE 1 SYSTEM

AAIA Part Type Description

Suspension Lift Kit
