ICON 05-07 Ford F-250/F-350 7in Stage 3 Suspension System

Manufacturer Part # : K67102

Market Description

ICON’s 7” Suspension System for the 2005-2007 Ford Super Duty’s offer unparalleled performance and ride quality while giving the vehicle clearance for 38” tall tires. This system comes complete with ICON 2.5 Aluminum Series Shocks, Dual-Rate Coil Springs, Drop Pitman Arm, Pan Rod Bracket, Brake Line Brackets, Radius Arm Drop Down Brackets, and ICON's Fabricated 6" Blocks and U-bolts. All of these components (excluding shocks) are covered by ICON’s Limited Lifetime Warranty.

Associated Comments

• APPLICATION NOTE #29: 7” Systems Using A 4-Link In Place Of The Factory Radius Arms Do Not Require The Use Of Alignment Cams. Caster Can Be Adjusted By The Lower Link Arms
• APPLICATION NOTE #28: Pinch Weld On ‘05-’10 Superduty Radius Arms May Come In Contact With Radius Arm Drop Bracket Hardware
• Recommended Aftermarket Tires: 37" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
• APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
• Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 5.00” Backspace / 6mm Offset
• APPLICATION NOTE #57: RETAINS FACTORY BLOCK FOR TRUCK TO SIT LEVEL WITH FRONT OF TRUCK
• Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.25” Backspace / 6mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.25” Backspace / 6mm Offset
• APPLICATION NOTE #21: NOT APPLICABLE ON VEHICLES EQUIPPED WITH A MANUAL TRANSMISSION
• APPLICATION NOTE #6: SPRINGS ARE RATED FOR DIESEL ENGINES ONLY
• OEM Wheels & Tires Fitment: Yes
• Ships in multiple boxes

Features and Benefits

• 100% Bolt-on system - No drilling, cutting, or welding necessary
• 7” more travel from ride height to front bump stops
• Lifetime guarantee that coil springs won’t sag
• State of the art dual-rate coil spring
• No driveshaft modifications needed
• Less body roll than stock truck
• 75% increase in wheel travel
• No change in towing capacity
• Clears 38" Tall Tires

Product Description - Extended

2005-2007 FORD F-250/F-350 7" LIFT STAGE 3 SUSPENSION SYSTEM

Product Description - Short

• ICON 05-07 Ford F-250/F-350 7in Stage 3 Suspension System
• SUSPENSION SYSTEM

Product Description - Long

05-07 FORD F-250/F-350 7" STAGE 3 SUSPENSION SYSTEM

Product Description - Invoice

05-07 F-250/F-350 7" STAGE 3 SYSTEM

AAIA Part Type Description

Suspension Lift Kit
